LEFT CRANKCASE COVER - ALTERNATOR (2)

VARIATOR - KICK STARTER SPINDLE FOR HONDA SCV 100 ACTIVA 2003

CLUTCH (SCV100CM2,5 / SCV1109,B)

FACE COMP., DRIVE

22102-KPL-900 22102KPL900

Not available

BOSS, DRIVE FACE

22105-KPL-900 22105KPL900

Not available

RATCHET, STARTER

22109-KPL-900 22109KPL900

Not available

FACE COMP., MOVABLE DRIVE

22110-KPL-900 22110KPL900

Not available

ROLLER COMP., WEIGHT

22121-KPL-900 22121KPL900

Not available

PLATE, RAMP

22131-KPL-900 22131KPL900

Not available

PIECE, SLIDE

22132-KPL-900 22132KPL900

Not available

SPRING, KICK DRIVEN GEAR

28223-GCC-000 28223GCC000

5,82 $

Unit Price

GEAR COMP., KICK DRIVEN

28230-KPL-900 28230KPL900

Not available

SPINDLE COMP., KICK STARTER

28250-KPL-900 28250KPL900

Not available

BUSH, KICK SPINDLE

28253-KPL-900 28253KPL900

Not available

COLLAR, KICK BOSS

28255-KPL-900 28255KPL900

0,26 $

Unit Price

SPRING, KICK RETURN

28281-GCC-000 28281GCC000

Not available

WASHER, THRUST, 10MM

90412-329-000 90412329000

4,49 $

Unit Price

WASHER, SPECIAL, 12MM

90426-KBN-900 90426KBN900

8,07 $

Unit Price

WASHER, KICK SPINDLE

90451-KPL-900 90451KPL900

Not available

NUT, HEX., 12MM

94001-122000S 94001122000S

1,82 $

Unit Price

CIRCLIP, EXTERNAL, 14MM

94511-14000 9451114000

1,82 $

Unit Price

ROLLER SET, WEIGHT

22123-KPL-305 22123KPL305

Not available

ROLLER SET, WEIGHT

22123-KPL-940 22123KPL940

Not available

PIECE SET, SLIDE

22011-KPL-940 22011KPL940

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the VARIATOR - KICK STARTER SPINDLE of your Honda SCV 100 ACTIVA of ACTIVA. Let us know if you have any questions.
