VARIATOR

CLUTCH FOR HONDA SCV 100 DIO AVIATOR 2003

GEARBOX

Item numbers

OUTER COMP., CLUTCH

22100-KPL-900 22100KPL900

Not available

PLATE COMP., DRIVE

22350-KPL-900 22350KPL900

Not available

SPRING, CLUTCH

22401-KPL-900 22401KPL900

Not available

SPRING, CLUTCH

22401-KPL-900 22401KPL900

Not available

SPRING, CLUTCH

22401-KPL-900 22401KPL900

Not available

WEIGHT SET, CLUTCH

22535-KPL-900 22535KPL900

Not available

RUBBER, CLUTCH DAMPER

22804-148-000 22804148000

3,94 $

Unit Price

RUBBER, CLUTCH DAMPER

22804-148-000 22804148000

3,94 $

Unit Price

RUBBER, CLUTCH DAMPER

22804-148-000 22804148000

3,94 $

Unit Price

BELT, DRIVE

23100-KPL-900 23100KPL900

Not available

FACE SET, DRIVEN

23205-KPL-900 23205KPL900

Not available

FACE COMP., MOVABLE DRIVEN

23220-KPL-900 23220KPL900

Not available

PIN, GUIDE ROLLER

23225-KPL-900 23225KPL900

Not available

PIN, GUIDE ROLLER

23225-KPL-900 23225KPL900

Not available

PIN, GUIDE ROLLER

23225-KPL-900 23225KPL900

Not available

ROLLER, GUIDE

23226-KPL-900 23226KPL900

Not available

ROLLER, GUIDE

23226-KPL-900 23226KPL900

Not available

ROLLER, GUIDE

23226-KPL-900 23226KPL900

Not available

SPRING, DRIVEN FACE

23233-KPL-900 23233KPL900

Not available

COLLAR, SEAL

23237-KPL-900 23237KPL900

Not available

COLLAR, SPRING

23238-KPL-900 23238KPL900

Not available

NUT, SPECIAL, 28MM

90202-KPL-900 90202KPL900

1,16 $

Unit Price

WASHER, THRUST, 6MM

90442-KPL-900 90442KPL900

Not available

WASHER, THRUST, 6MM

90442-KPL-900 90442KPL900

Not available

WASHER, THRUST, 6MM

90442-KPL-900 90442KPL900

Not available

CIRCLIP, INTERNAL, 24

90601-KPL-900 90601KPL900

Not available

CIRCLIP, 5MM

90603-KPL-900 90603KPL900

Not available

CIRCLIP, 5MM

90603-KPL-900 90603KPL900

Not available

CIRCLIP, 5MM

90603-KPL-900 90603KPL900

Not available

BEARING, RADIAL BALL, 6901U

91006-GAZ-980 91006GAZ980

Not available

BEARING, NEEDLE, 17X25X18

91103-GAZ-980 91103GAZ980

Not available

OIL SEAL, 34X39X3 (ARAI)

91211-GK8-013 91211GK8013

Not available

OIL SEAL, 34X39X3 (ARAI)

91211-GK8-013 91211GK8013

Not available

O-RING, 38.5X2

91351-GR1-000 91351GR1000

5,08 $

Unit Price

O-RING, PINION CAP

91351-642-000 91351642000

6,92 $

Unit Price

NUT, FLANGE, 10MM

94050-10000 9405010000

4,04 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CLUTCH of your Honda SCV 100 DIO AVIATOR of AVIATOR. Let us know if you have any questions.
