EXHAUST MUFFLER

PEDAL FOR HONDA ATC 250 BIG RED 1985

DRIVESHAFT - REAR ARM (1)

PEDAL Honda ATV 250 ATC 1985 ATC250ESF
1
PEDAL COMP CHANG

24700-HA0-000  

24700HA0000
Not available
1
PEDAL COMP CHANG

24700-HA0-010  

24700HA0010
Not available
2
RUBBER, CHANGE PEDAL

24781-371-000   24781371000

24781371000

Unit Price

3
JOINT, KICK ARM

28241-HA0-000   28241HA0000

28241HA0000
Not available
4
ARM ASSY., KICK STARTER

28300-HA0-000   28300HA0000

28300HA0000
Not available
5
PLUG, KICK ARM

28302-965-000   28302965000

28302965000

Unit Price

6
SPRING, KICK STARTER STOPPER
SPRING, KICK STARTER STOPPER

28333-124-000   28333124000

28333124000

Unit Price

7
CLAMP, HIGH TENSION CORD

32802-MB2-000   32802MB2000

32802MB2000
Not available
8
CABLE, R. FOOT BRAKE

43470-HA0-000   43470HA0000

43470HA0000
Not available
9
PEDAL COMP BRK

46500-HA0-000  

46500HA0000
Not available
10
SPRING, BRAKE PEDAL

46514-HA0-000   46514HA0000

46514HA0000
Not available
11
PIN STEP JOINT

50603-964-670  

50603964670
Not available
12
STEP COMP R

50610-964-670  

50610964670
Not available
13
PLATE COMP., R. STEP

50615-HA0-000   50615HA0000

50615HA0000
Not available
14
PLATE COMP., L. STEP

50616-HA0-000   50616HA0000

50616HA0000
Not available
15
SPRING R ETEP RET

50617-964-000  

50617964000
Not available
16
SPG L STEP RETURN

50618-964-000  

50618964000
Not available
17
STEP COMP L

50620-964-670  

50620964670
Not available
18
ARM ASSY R STEP

50630-HA0-000  

50630HA0000
Not available
19
ARM ASSY L STEP

50640-HA0-000  

50640HA0000
Not available
20
SCREW OVAL 6X28

90104-965-003  

90104965003
Not available
21
WASHER, THRUST, 8MM

90450-147-000   90450147000

90450147000

Unit Price

22
WASHER, 17.5MM

90512-303-000   90512303000

90512303000

Unit Price

23
DUST SEAL, 17X23X3 (NOK)

91206-968-003   91206968003

91206968003

Unit Price

24
O-RING, 14MM (ARAI)

91353-671-003   91353671003

91353671003

Unit Price

25
BOLT, HEX., 6X25

92025-060250A   92025060250A

92025060250A
Not available
26
NUT HEX 6MM
NUT HEX 6MM

94001-060000S  

94001-06200
 94001060000S

Unit Price

27
PIN, SPLIT, 1.6X15
PIN, SPLIT, 1.6X15

94201-16150   9420116150

9420116150

Unit Price

28
PIN C0TTER 30X45

94201-30250  

94201-30300
 9420130250

Unit Price

29
SPG A BRAKE ROD

43467-HA0-000  

95014-73100
 43467HA0000

Unit Price

29
SPRING A, BRAKE ROD
SPRING A, BRAKE ROD

95014-73100   9501473100

9501473100

Unit Price

30
BOLT FLANGE 6X20

95700-0602000  

95801-0602000
 957000602000

Unit Price

31
BOLT FLANGE 8X28

95700-0802808  

95701-0802808
 957000802808

Unit Price

32
BOLT FLANGE 10X35

95800-1003500  

95801-1003500
 958001003500

Unit Price

33
BALL, STEEL, #8 (1/4)
BALL, STEEL, #8 (1/4)

96211-08000   9621108000

9621108000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the PEDAL of your Honda ATC 250 BIG RED of ATC. Let us know if you have any questions.

Genuine parts for Honda 1985 ATC 250 BIG RED

Engine Frame

Honda 1985 ATC 250 BIG RED

Please choose your model in the list above and click on its Genuine Spare Parts Catalogue

Color : R109
250 ATC 1985 ATC250ESF
Color : R109

ATC 250 BIG RED

Honda ATC

Displacement: 250 cc
Year: 1985
Model code ATC250ESF
Color: R109
Drapeau AUSTRALIA
Australia
The engine is 246 cm3, OHC single cylinder, 5 speed, automatic clutch. Fuel tank strip is silver, gray and black, seat color is black, electric start, shaft drive, reverse gear.

Technical specifications

Engine oil quantity:
2,5 Liters
