FRONT FORK FOR HONDA ATC 250 BIG RED 1987

FRONT BRAKE PANEL - SHOES

RECEIVER, BRAKE CABLE

50142-HA0-000 50142HA0000

Not available

FORK ASSY., R. FR.

51400-HA0-681 51400HA0681

Not available

SPRING, FR. CUSHION

51401-HA0-003 51401HA0003

Not available

PIPE COMP., FR. FORK

51410-HA0-003 51410HA0003

Not available

SPRING, FR. FORK REBOUND

51412-340-000 51412340000

6,22 $

Unit Price

CASE COMP., R. BOTTOM

51420-HA0-681 51420HA0681

Not available

SPACER FR CUSHION

51422-376-003

Not available

DUST SEAL

51425-473-003 51425473003

Not available

PIECE OIL LOCK

51432-388-003

51432-447-731

36,97 $

Unit Price

RING, PISTON

51437-400-771 51437400771

10,04 $

Unit Price

PIPE, SEAT

51440-HA0-003 51440HA0003

Not available

SEAT, SPRING UPPER

51454-HA0-003 51454HA0003

Not available

RING, STOPPER

51456-HA0-003 51456HA0003

Not available

SEAL SET, FR. FORK

51490-473-305 51490473305

FORK ASSY., L. FR.

51500-HA0-681 51500HA0681

Not available

CASE COMP., L. BOTTOM

51520-HA0-681 51520HA0681

Not available

BOOT, FR. FORK

51611-KL8-003 51611KL8003

70,56 $

Unit Price

BAND FR FORK BOOT

51612-473-000

51612-428-900

14,65 $

Unit Price

HOLDER AXL*NH35M*

51634-HA0-003

51634-MK5-003ZD

40,98 $

Unit Price

8MM SOCKET BOLT

90116-283-010

90116-383-721

8,63 $

Unit Price

WASHER, SPECIAL, 8MM

90544-283-000 90544283000

3,42 $

Unit Price

RING, OIL SEAL STOP

90601-369-000 90601369000

5,88 $

Unit Price

O-RING

91356-HA0-003 91356HA0003

Not available

SCREW, PAN, 3X20

93500-030200G 93500030200G

1,14 $

Unit Price

NUT, U, 6MM

90301-473-003 90301473003

4,98 $

Unit Price

BOLT FLANGE 6X16

96000-0601600

96001-0601600

1,34 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRONT FORK of your Honda ATC 250 BIG RED of ATC. Let us know if you have any questions.

Please choose your model in the list above and click on its Genuine Spare Parts Catalogue

ATC 250 BIG RED

Honda ATC

Displacement: 250 cc
Year: 1987
Model code ATC250ESH
Color: R109

Usa

Add to my garage

The engine is 246 cm3, OHC single cylinder, 5 speed, automatic clutch. Fuel tank strip is silver, gray and black, seat color is gray, electric start, shaft drive, reverse gear.
