REAR ARM - DRIVE CHAIN (4)

REAR SHOCK ABSORBER (3) FOR HONDA CR 250 R 1987

REAR FENDER

REAR SHOCK ABSORBER (3) Honda MOTO 250 CR 1987 CR250RH
1
CUSHION ASSY., RR. (SHOWA)

52400-KS7-751   52400KS7751

52400KS7751
Not available
2
SPRING, RR. CUSHION (SHOWA) (47.07N/MM, 4.8KG/MM WHITE)

52401-KS7-751   52401KS7751

52401KS7751
Not available
2
SPRING, RR. CUSHION (SHOWA) (50.99N/MM, 5.2KG/MM PINK)

52401-KS7-771   52401KS7771

52401KS7771
Not available
2
SPRING, RR. CUSHION (SHOWA) (43.15N/MM, 4.4KGF/MM ORANGE)

52402-KS7-751   52402KS7751

52402KS7751
Not available
2
SPRING, RR. CUSHION (SHOWA) (47.07N/MM, 4.8KG/MM WHITE)

52402-KS7-771   52402KS7771

52402KS7771
Not available
3
DAMPER COMP., RR. (SHOWA)

52410-KS7-751   52410KS7751

52410KS7751
Not available
4
SEAT, RUBBER (SHOWA)

52417-KA4-831   52417KA4831

52417KA4831
Not available
5
RING C, STOPPER (SHOWA)

52418-KA4-831   52418KA4831

52418KA4831
Not available
6
WASHER

52419-KS7-701   52419KS7701

52419KS7701
Not available
7
ROD COMP., PISTON (SHOWA)

52421-KS7-751   52421KS7751

52421KS7751
Not available
8
ADJUSTER, SPRING

52422-KS7-701   52422KS7701

52422KS7701
Not available
9
NUT, ADJUSTER

52423-KS7-701   52423KS7701

52423KS7701
Not available
10
STOPPER, SPRING SEAT

52424-KS7-701   52424KS7701

52424KS7701
Not available
11
CASE DAMPER

52425-KS7-701  

52425KS7701
Not available
12
CASE COMP., DAMPER (SHOWA)

52425-KS7-751   52425KS7751

52425KS7751
Not available
13
CAP, AIR VALVE

52425-381-771   52425381771

52425381771
Not available
14
ROD COMP.

52426-KS7-701   52426KS7701

52426KS7701
Not available
15
RUBBER, STOPPER

52427-KS7-701   52427KS7701

52427KS7701
Not available
16
PLATE, END (SHOWA)

52428-KA4-832   52428KA4832

52428KA4832
Not available
17
CASE COMP., ROD GUIDE (SHOWA)

52429-KA4-831   52429KA4831

52429KA4831
Not available
18
RING, PISTON

52431-KA4-831   52431KA4831

52431KA4831

Unit Price

19
RING, STOPPER (SHOWA)

52435-KA4-831   52435KA4831

52435KA4831
Not available
20
OIL SEAL SET (SHOWA)

52436-KA4-841   52436KA4841

52436KA4841
Not available
21
O-RING SET

52437-KA4-841   52437KA4841

52437KA4841

Unit Price

22
BOLT COMP., PLUG (SHOWA)

52440-KS7-751   52440KS7751

52440KS7751
Not available
23
VALVE KIT, RR. DAMPER

52442-KS7-305   52442KS7305

52442KS7305
Not available
24
SCREW, PAN

52448-KS7-003   52448KS7003

52448KS7003
Not available
25
PLATE, ADJUSTING (B)

52449-KS7-701   52449KS7701

52449KS7701
Not available
26
BLADDER (SHOWA)

52451-KS7-701   52451KS7701

52451KS7701
Not available
27
RING, STOPPER (SHOWA)

52452-KS7-701   52452KS7701

52452KS7701
Not available
28
CAP COMP., CHAMBER (SHOWA)

52453-KS7-701   52453KS7701

52453KS7701
Not available
29
BOLT, DRAIN (SHOWA)

52454-KS7-701   52454KS7701

52454KS7701
Not available
30
SEAT, SPRING

52458-KS7-701   52458KS7701

52458KS7701
Not available
31
ARM ASSY., CUSHION

52460-KA3-831   52460KA3831

52460KA3831
Not available
32
BUSH, CUSHION ARM
BUSH, CUSHION ARM

52462-KA3-831   52462KA3831

52462KA3831
33
COLLAR, CUSHION ARM PIVOT
COLLAR, CUSHION ARM PIVOT

52463-KA3-830   52463KA3830

52463KA3830
Not available
34
COLLAR, CUSHION ARM
COLLAR, CUSHION ARM

52464-KA3-830   52464KA3830

52464KA3830
Not available
35
ROD ASSY., CUSHION CONNECTING

52470-KS6-000   52470KS6000

52470KS6000
Not available
36
BUSH, CUSHION CONNECTING ROD THRUST
BUSH, CUSHION CONNECTING ROD THRUST

52472-KA3-831   52472KA3831

52472KA3831

Unit Price

37
COLLAR, CONNECTING ROD PIVOT
COLLAR, CONNECTING ROD PIVOT

52473-KA3-830   52473KA3830

52473KA3830
Not available
38
COLLAR, DAMPER UPPER

52486-KA3-731   52486KA3731

52486KA3731
Not available
39
RING, STOPPER
RING, STOPPER

52487-KA3-731   52487KA3731

52487KA3731
Not available
40
RING, STOPPER

52487-KA4-831   52487KA4831

52487KA4831

Unit Price

41
LABEL, RR. DAMPER WARNING

87516-KS7-771   87516KS7771

87516KS7771
Not available
42
BOLT, SOCKET, 12X86

90128-KS6-700   90128KS6700

90128KS6700
Not available
43
BOLT, FLANGE, 10X77

90129-KF0-000   90129KF0000

90129KF0000

Unit Price

44
BOLT, FLANGE, 10X83

90130-KS6-700   90130KS6700

90130KS6700
Not available
45
BOLT, FLANGE, 10X48

90153-KA3-730   90153KA3730

90153KA3730
Not available
46
BOLT FLANGE 10X52

90154-KA3-830  

90154KA3830
Not available
47
NUT, AXLE, 10MM

90304-GA6-003   90304GA6003

90304GA6003

Unit Price

48
NUT FLANGE 12MM

90306-KA4-003  

90306-181-761
 90306KA4003

Unit Price

49
WASHER, SPECIAL, 8MM

90544-283-000   90544283000

90544283000

Unit Price

50
BRG SPHER 14MM
BRG SPHER 14MM

91077-KA3-731  

91077-KA4-831
 91077KA3731

Unit Price

51
BEARING, SPHERICAL, 10.1MM

91077-KS7-013   91077KS7013

91077KS7013

Unit Price

52
BEARING, NEEDLE, 19.1X26.1X27 (NTN)
BEARING, NEEDLE, 19.1X26.1X27 (NTN)

91078-KA3-831   91078KA3831

91078KA3831
Not available
53
BEARING, NEEDLE, 17.5X24.5X22
BEARING, NEEDLE, 17.5X24.5X22

91079-KA3-831   91079KA3831

91079KA3831
54
O-RING, 15.5X1.5

91256-GC5-003   91256GC5003

91256GC5003

Unit Price

55
O-RING, 19.8X2.4

91256-GE2-003   91256GE2003

91256GE2003
Not available
56
SEAL, CUSHION ARM PIVOT
SEAL, CUSHION ARM PIVOT

91261-KS6-701   91261KS6701

91261KS6701
57
SEAL, CUSHION CONNECTING ROD PIVOT (ARAI)
SEAL, CUSHION CONNECTING ROD PIVOT (ARAI)

91262-KA3-831   91262KA3831

91262KA3831
Not available
58
DUST SEAL, RR. CUSHION UPPER
DUST SEAL, RR. CUSHION UPPER

91351-KA3-731   91351KA3731

91351KA3731
Not available
59
DUST SEAL, RR. CUSHION UPPER
DUST SEAL, RR. CUSHION UPPER

91351-KS7-003   91351KS7003

91351KS7003

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Honda, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for Honda 1987 CR 250 R

Engine Frame

Honda 1987 CR 250 R

Select your CR 250 in the list above and click on its Genuine Spare Parts Catalog

Color : R119
250 CR 1987 CR250RH
Color : R119

CR 250 R

Honda CR

Displacement: 250 cc
Year: 1987
Model code CR250RH
Color: R119
Drapeau CALIFORNIA
California
The engine installed in the CR250R has improved output (47.5PS/8500rpm→50PS/8000rpm) by changing the operating characteristics of Honda\'s original H.P.P.P (Honda Power Port), which can achieve powerful combustion due to excellent filling efficiency, and improvements in the intake and exhaust systems. In addition, the popular NS cylinder, which is coated with nickel and silicon carbide on the inner wall of the cylinder, and hard chrome-plated piston rings are newly adopted to improve heat resistance and durability as the engine increases output.
