Displacement

Model

Year

Finish line

FRONT FORK FOR HONDA CRF 250 M 2019

FRONT BRAKE CALIPER

(1) 45461-KZZ-J00

CLAMPER A, BRAKE HOSE

(2) 45462-KZZ-J00

CLAMPER B, FR. BRAKE HOSE

(3) 51400-KZZ-G11

FORK ASSY., R. FR. (SHOWA) (###)

(4) 51401-KZZ-A21

SPRING, FR. FORK

(5) 51410-KZZ-A21

TUBE, OUTER

(6) 51412-KA4-711

RING, BACK UP

(7) 51412-KZZ-901

SPRING, REBOUND

(8) 51414-MFN-D01

BUSH, GUIDE

(9) 51415-MGP-D01

BUSH, SLIDER

(10) 51419-KZZ-901

SEAT STOPPER --- SIEGE, BUTEE

(11) 51425-KZZ-G11

PIPE COMP., R. SLIDE (SHOWA)

(12) 51426-KZZ-901

STEM COMP., STEERING

(13) 51430-KZZ-D21

DAMPER COMP., FR.

(14) 51447-KA4-711

RING, OIL SEAL STOPPER

(15) 51450-KZZ-901

BOLT COMP., FR. FORK

(16) 51451-MAJ-G41

NUT, HEX., 10MM

(17) 51456-KZZ-901

RING, STOPPER

(18) 51476-MFB-003

RING, WEAR

(19) 51490-KZZ-J01

SEAL SET, FR. FORK

(20) 51500-KZZ-G11

FORK ASSY., L. FR. (SHOWA)

(21) 51426-KZZ-G11

PIPE COMP., L. SLIDE (SHOWA)

(22) 51610-KZZ-A20

PROTECTOR, R. FR. FORK *TNATURAL*

(23) 51620-KZZ-A20

PROTECTOR, L. FR. FORK *TNATURAL*

(24) 90106-KZZ-900

BOLT PROTECTOR --- BOULON, PROTECTEUR (6MM)

(25) 90107-MGE-000

BOLT, FLANGE, 8X40

(26) 90113-KZZ-900

BOLT, FLANGE, 6MM

(27) 90116-KV3-701

BOLT, SOCKET, 8MM

(28) 90544-283-000

WASHER, SPECIAL, 8MM

(29) 91254-ML3-791

DUST SEAL

(30) 91356-KZ3-003

O-RING, 44.7X2.4

	Part number	Description	Qty
# 1	45461-KZZ-J00 45461KZZJ00 45461KZZJ00	CLAMPER A, BRAKE HOSE	1,89 $
# 2	45462-KZZ-J00 45462KZZJ00 45462KZZJ00	CLAMPER B, FR. BRAKE HOSE	2,72 $
# 3	51400-KZZ-G11 51400KZZG11 51400KZZG11	FORK ASSY., R. FR. (SHOWA) (###)	Contact	0,00 $
# 4	51401-KZZ-A21 51401KZZA21 51401KZZA21	SPRING, FR. FORK	Contact	0,00 $
# 5	51410-KZZ-A21 51410KZZA21 51410KZZA21	TUBE, OUTER	Contact	0,00 $
# 6	51412-KA4-711 51412KA4711 51412KA4711	RING, BACK UP	11,80 $
# 7	51412-KZZ-901 51412KZZ901 51412KZZ901	SPRING, REBOUND	9,10 $
# 8	51414-MFN-D01 51414MFND01 51414MFND01	BUSH, GUIDE	12,62 $
# 9	51415-MGP-D01 51415MGPD01 51415MGPD01	BUSH, SLIDER	24,76 $
# 10	51419-KZZ-901 51419KZZ901 51419KZZ901	SEAT STOPPER --- SIEGE, BUTEE	7,89 $
# 11	51425-KZZ-G11 51425KZZG11 51425KZZG11	PIPE COMP., R. SLIDE (SHOWA)	Contact	0,00 $
# 12	51426-KZZ-901 51426KZZ901 51426KZZ901	STEM COMP., STEERING	163,52 $
# 13	51430-KZZ-D21 51430KZZD21 51430KZZD21	DAMPER COMP., FR.	143,86 $
# 14	51447-KA4-711 51447KA4711 51447KA4711	RING, OIL SEAL STOPPER	5,86 $
# 15	51450-KZZ-901 51450KZZ901 51450KZZ901	BOLT COMP., FR. FORK	47,83 $
# 16	51451-MAJ-G41 51451MAJG41 51451MAJG41	NUT, HEX., 10MM	3,04 $
# 17	51456-KZZ-901 51456KZZ901 51456KZZ901	RING, STOPPER	4,05 $
# 18	51476-MFB-003 51476MFB003 51476MFB003	RING, WEAR	9,56 $
# 19	51490-KZZ-J01 51490KZZJ01 51490KZZJ01	SEAL SET, FR. FORK	41,60 $
# 20	51500-KZZ-G11 51500KZZG11 51500KZZG11	FORK ASSY., L. FR. (SHOWA)	Contact	0,00 $
# 21	51426-KZZ-G11 51426KZZG11 51426KZZG11	PIPE COMP., L. SLIDE (SHOWA)	Contact	0,00 $
# 22	51610-KZZ-A20 51610KZZA20 51610KZZA20	PROTECTOR, R. FR. FORK TNATURAL	Contact	0,00 $
# 23	51620-KZZ-A20 51620KZZA20 51620KZZA20	PROTECTOR, L. FR. FORK TNATURAL	Contact	0,00 $
# 24	90106-KZZ-900 90106KZZ900 90106KZZ900	BOLT PROTECTOR --- BOULON, PROTECTEUR (6MM)	3,42 $
# 25	90107-MGE-000 90107MGE000 90107MGE000	BOLT, FLANGE, 8X40	3,16 $
# 26	90113-KZZ-900 90113KZZ900 90113KZZ900	BOLT, FLANGE, 6MM	3,75 $
# 27	90116-KV3-701 90116KV3701 90116KV3701	BOLT, SOCKET, 8MM	4,95 $
# 28	90544-283-000 90544283000 90544283000	WASHER, SPECIAL, 8MM	3,10 $
# 29	91254-ML3-791 91254ML3791 91254ML3791	DUST SEAL	22,08 $
# 30	91356-KZ3-003 91356KZ3003 91356KZ3003	O-RING, 44.7X2.4	6,07 $

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Honda, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
