CRANKSHAFT - PISTON

GEARBOX FOR HONDA VT 250 F XELVIS 1992

GEARSHIFT DRUM

Item numbers

MAINSHAFT COMP.

23210-KV0-720 23210KV0720

Not available

COUNTERSHAFT COMP.

23220-KV0-721 23220KV0721

Not available

GEAR, COUNTERSHAFT LOW (37T) (41T)

23421-KY1-000 23421KY1000

149,45 $

Unit Price

COLLAR, 20X8

23422-KY1-000 23422KY1000

20,40 $

Unit Price

GEAR, MAINSHAFT SECOND (16T) (19T)

23431-KY1-000 23431KY1000

Not available

GEAR, COUNTERSHAFT SECOND (38T)

23441-KY1-010 23441KY1010

Not available

COLLAR, 25X8

23442-KV0-720 23442KV0720

20,40 $

Unit Price

GEAR, MAINSHAFT THIRD & FOURTH (15T/19T) (22T/24T)

23451-KV0-720 23451KV0720

Not available

GEAR, COUNTERSHAFT THIRD (35T)

23461-KY1-010 23461KY1010

Not available

COLLAR, SPLINE, 25X8

23462-KY1-000 23462KY1000

Not available

COLLAR, SPLINE, 25X8

23462-KY1-000 23462KY1000

Not available

GEAR, COUNTERSHAFT FOURTH (32T)

23481-KY1-010 23481KY1010

Not available

GEAR, MAINSHAFT FIFTH (26T)

23491-KY1-010 23491KY1010

Not available

COLLAR, 22X13

23495-KY1-000 23495KY1000

19,66 $

Unit Price

GEAR, COUNTERSHAFT FIFTH (30T)

23501-KY1-010 23501KY1010

Not available

GEAR, MAINSHAFT SIXTH (24T) (28T)

23511-KY1-010 23511KY1010

Not available

COLLAR, SPLINE, 22X14

23512-KEA-000 23512KEA000

26,83 $

Unit Price

GEAR, COUNTERSHAFT SIXTH (24T) (29T)

23521-KY1-010 23521KY1010

Not available

SPROCKET, DRIVE (14T)

23801-KV0-720 23801KV0720

Not available

PIN, GEARSHIFT FORK GUIDE

24261-283-000 24261283000

6,02 $

Unit Price

PIN, GEARSHIFT FORK GUIDE

24261-283-000 24261283000

6,02 $

Unit Price

BOLT, SPECIAL, 10MM

90037-422-003 90037422003

10,53 $

Unit Price

WASHER, THRUST, 25.2X34

90446-KV0-720 90446KV0720

5,16 $

Unit Price

WASHER, THRUST, 17.2MM

90446-357-000 90446357000

6,59 $

Unit Price

WASHER, SPLINE, 22MM

90451-KY1-000 90451KY1000

5,46 $

Unit Price

WASHER, SPLINE, 22MM

90451-KY1-000 90451KY1000

5,46 $

Unit Price

WASHER, SPLINE, 22MM

90451-KY1-000 90451KY1000

5,46 $

Unit Price

WASHER, SPLINE, 25X31X1.5

90451-KY2-000 90451KY2000

5,59 $

Unit Price

WASHER, SPLINE, 25X31X1.5

90451-KY2-000 90451KY2000

5,59 $

Unit Price

WASHER, SPLINE, 25X31X1.5

90451-KY2-000 90451KY2000

5,59 $

Unit Price

WASHER, THRUST, 20X1.00

90454-428-000 90454428000

4,19 $

Unit Price

WASHER, THRUST, 20X1.00

90454-428-000 90454428000

4,19 $

Unit Price

WASHER, 10.2MM

90459-438-000 90459438000

8,52 $

Unit Price

WASHER, SPLINE, 25MM

90461-KY2-000 90461KY2000

6,16 $

Unit Price

WASHER, LOCK, 25MM

90462-KAZ-000 90462KAZ000

11,31 $

Unit Price

RING, BEARING SETTING, 56MM

90601-MA6-000 90601MA6000

4,99 $

Unit Price

SET RING, 52MM

90601-ML0-000 90601ML0000

Not available

CIRCLIP, 25MM

90601-107-000 90601107000

5,30 $

Unit Price

CIRCLIP, 25MM

90601-107-000 90601107000

5,30 $

Unit Price

CIRCLIP, 25MM

90601-107-000 90601107000

5,30 $

Unit Price

CIRCLIP, 22MM

90601-329-000 90601329000

3,44 $

Unit Price

CIRCLIP, 22MM

90601-329-000 90601329000

3,44 $

Unit Price

CIRCLIP, 22MM

90601-329-000 90601329000

3,44 $

Unit Price

BEARING, RADIAL BALL, 6322 (NTN)

91004-MA6-003 91004MA6003

Not available

BEARING, NEEDLE, 17MM (NTN)

91021-KE8-003 91021KE8003

Not available

BEARING, NEEDLE, 20MM (NTN)

91022-KT7-003 91022KT7003

Not available

OIL SEAL, 34X52X9 (ARAI)

91205-KT7-003 91205KT7003

24,73 $

Unit Price

OIL SEAL 34X52X9

91205-KT7-004

91205-KT7-003

24,73 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the GEARBOX of your Honda VT 250 F XELVIS of VT. Let us know if you have any questions.
