GEARSHIFT FORK - GEARSHIFT DRUM

CARBURETOR O.P. KIT FOR HONDA XLR 250 BAJA 1991

GASKET KIT

GASKET SET

16010-KR6-004

16010-KR6-305

47,66 $

Unit Price

FLOAT SET

16013-439-921 16013439921

124,69 $

Unit Price

TOP SET

16014-KR6-004

Not available

CHAMBER SET, FLOAT

16015-428-771 16015428771

Not available

SCREW SET A

16016-393-701

16016-393-700

31,55 $

Unit Price

ARM SET, LINK

16018-471-014 16018471014

Not available

SCREW SET B

16028-KN5-671 16028KN5671

Not available

LINK SET, THROTTLE

16032-KV6-004 16032KV6004

Not available

PACKING SET B --- VEU DE JOINT B

16040-460-004 16040460004

Not available

VALVE THROTTLE

16111-KR6-014

Not available

VALVE COMP., FLOAT

16155-413-751 16155413751

53,12 $

Unit Price

HOLDER NEEDLE JET

16165-428-671

Not available

HOLDER, JET

16168-382-014 16168382014

11,37 $

Unit Price

BINDER

16179-428-671 16179428671

Not available

T-JOINT

16180-195-731 16180195731

Not available

TUBE, 3.5X50 (95005-35001-20M)

16199-KZ9-004 16199KZ9004

Not available

TUBE, FUEL

16199-KB4-791 16199KB4791

Not available

TUBE

16199-KR6-004 16199KR6004

12,01 $

Unit Price

TUBE

16199-402-004

16199-GJ3-601

12,05 $

Unit Price

SCREW, PAN, 3X8

93500-030080H 93500030080H

0,82 $

Unit Price

SCREW, FLAT, 5X10

93600-050100H 93600050100H

0,82 $

Unit Price

SCREW-WASHER, 4X8

93892-0400808 938920400808

1,68 $

Unit Price

SCREW WASHER 4X10

93892-0401010

93892-0401000

0,83 $

Unit Price

SCREW-WASHER, 4X12

93892-0401208 938920401208

1,75 $

Unit Price

SREW WASHER 4X14

93892-0401418

93892-0401408

1,68 $

Unit Price

SCREW-WASHER, 4X16

93892-0401608 938920401608

1,52 $

Unit Price

SCREW-WASHER, 5X10

93892-0501008 938920501008

1,42 $

Unit Price

WASHER, SPRING, 3MM

94111-03800 9411103800

0,82 $

Unit Price

CLIP, TUBE (B6.5)

95002-02650 9500202650

1,62 $

Unit Price

JET #118

99101-3931180

99101-GHB1180

19,47 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CARBURETOR O.P. KIT of your Honda XLR 250 BAJA of XL. Let us know if you have any questions.
