OIL PUMP

CRANKCASE FOR HONDA XR 250 TORNADO 2018

CRANKSHAFT

CRANKCASE COMP., R.

11100-KPF-900 11100KPF900

Not available

PLATE, BREATHER

11110-KPF-900 11110KPF900

16,53 $

Unit Price

GASKET, CRANKCASE

11191-KPF-901 11191KPF901

Not available

CRANKCASE COMP., L.

11200-KPF-900 11200KPF900

Not available

SCREEN, OIL FILTER

15421-KK0-000 15421KK0000

14,91 $

Unit Price

PLATE, BEARING SETTING

23521-KK0-000 23521KK0000

Not available

PLATE B, BEARING SETTING

23522-KW3-000 23522KW3000

6,84 $

Unit Price

SWITCH ASSY., NEUTRAL (TEC)

35600-413-023 35600413023

30,82 $

Unit Price

GUIDE, NEUTRAL SWITCH

35601-KG0-000 35601KG0000

Not available

BOLT, FLANGE, 6X16 (NSHF)

90004-GHB-630 90004GHB630

5,92 $

Unit Price

BOLT FLANGE 6X35

90004-GHB-700

90001-GHB-700

6,02 $

Unit Price

BOLT, FLANGE, 6X55 (NSHF)

90004-GHB-740 90004GHB740

6,81 $

Unit Price

BOLT, FLANGE, 6X70 (NSHF)

90004-GHB-770 90004GHB770

9,16 $

Unit Price

BOLT, FLANGE, 6X90 (NSHF)

90004-GHB-810 90004GHB810

7,70 $

Unit Price

BOLT, DRAIN PLUG, 12MM

90131-KRM-840 90131KRM840

2,38 $

Unit Price

WASHER 12MM DRAIN

90401-KRM-R20

94109-12000

0,87 $

Unit Price

WASHER, 4.2MM

90408-KPF-960 90408KPF960

Not available

WASHER, NEUTRAL SWITCH

90443-KR0-000 90443KR0000

2,36 $

Unit Price

WASHER, SEALING, 6MM

90488-425-000 90488425000

3,56 $

Unit Price

DOWEL PIN, 8X14

90702-KRM-840 90702KRM840

1,13 $

Unit Price

BEARING, NEEDLE, 1010 (NTN)

91022-KPF-961 91022KPF961

Not available

NUT, HEX., 4MM

94001-040000S 94001040000S

0,82 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CRANKCASE of your Honda XR 250 TORNADO of XR. Let us know if you have any questions.
