GEARSHIFT DRUM

CARBURETOR FOR HONDA CMX 450 1987

GASKET KIT

GASKET SET

16010-MM2-791 16010MM2791

Not available

FLOAT SET

16013-MA6-003

16013-KR3-980

90,26 $

Unit Price

SCREW SET A

16016-MJ8-004

Not available

CHAMBER SET FLOAT

16023-MM2-671

Not available

JOINT SET, FUEL

16026-MM2-671 16026MM2671

Not available

SCREW SET B

16028-KR3-671 16028KR3671

SCREW SET

16029-KE8-004

Not available

TUBE SET, FUEL (A)

16034-MM2-671 16034MM2671

Not available

PLATE SET, VALVE

16037-ME5-671 16037ME5671

41,14 $

Unit Price

NEEDLE SET, JET

16012-MM2-792 16012MM2792

Not available

TUBE SET, FUEL (B)

16042-MM2-671 16042MM2671

Not available

STARTER VALVE SET

16046-MM2-671

16046-ML4-611

93,38 $

Unit Price

VALVE SET AIR CUT

16048-KR0-003

Not available

SPRING, VACUUM PISTON

16050-ML4-611 16050ML4611

Not available

SPRING

16052-MB0-671 16052MB0671

9,16 $

Unit Price

SPRING, COMPRESSION COIL

16053-MM2-671 16053MM2671

Not available

SPRING

16054-MA6-003 16054MA6003

Not available

SCREW, PAN, 6X12

16080-ML4-611 16080ML4611

Not available

PAN SCREW 4X8

16081-MM2-671

Not available

CARBURETOR ASSY.

16100-MM2-792 16100MM2792

Not available

CARBURETOR ASSY., R.

16101-MM2-792 16101MM2792

Not available

CARBURETOR ASSY., L.

16102-MM2-792 16102MM2792

Not available

TOP COMP

16108-ME5-671

Not available

PISTON COMP., VACUUM

16111-MM2-771 16111MM2771

Not available

LEVER STARTER

16120-MM2-671

Not available

LEVER, STARTER

16121-MA6-003 16121MA6003

14,49 $

Unit Price

STATER LINK SHAFT

16145-MM2-671

Not available

VALVE COMP., FLOAT

16155-397-971 16155397971

63,79 $

Unit Price

HOLDER NEEDLE JET

16165-KR0-003

Not available

BINDER

16179-HA0-003 16179HA0003

Not available

CLIP PLATE

16179-ML4-651

Not available

TUBE, AIR VENT

16198-MM2-671 16198MM2671

Not available

JOINT A, VACUUM TUBE

17201-MG9-000 17201MG9000

Not available

SCREW, PAN, 4X8

93500-040080A 93500040080A

0,82 $

Unit Price

SCREW, PAN, 5X10

93500-050100A 93500050100A

0,82 $

Unit Price

SCREW-WASHER, 4X10

93892-0401008 938920401008

1,52 $

Unit Price

SCREW-WASHER, 4X12

93892-0401200 938920401200

0,82 $

Unit Price

SCREW-WASHER, 4X14

93892-0401400 938920401400

Not available

CLIP, TUBE (B7)

95002-02070 9500202070

2,08 $

Unit Price

CLIP, TUBE (B7)

95002-02070 9500202070

2,08 $

Unit Price

CLIP, TUBE (B6.5)

95002-02650 9500202650

1,62 $

Unit Price

TUBE 1 35X100

95005-3509010

Not available

JET #112

99101-3931120

99110-GHB1120

10,32 $

Unit Price

JET, SLOW, #38

99103-MA40380 99103MA40380

16,87 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CARBURETOR of your Honda CMX 450 of CM. Let us know if you have any questions.
