FOOTREST

REAR ARM - CHAIN CASE FOR HONDA XR 600 R 1986

REAR SHOCK ABSORBER

REAR ARM - CHAIN CASE Honda MOTO 600 XR 1986 XR600RG
2
CASE, DRIVE CHAIN

40510-KN5-670   40510KN5670

40510KN5670
Not available
8
CHAIN, DRIVE (DAIDO) (520V.4-110FJ)

40530-MK2-003  

40530MK2003
Not available
8
CHAIN DRIVE

40530-MK2-005  

40530MK2005
Not available
9
JOINT, DRIVE CHAIN (DAIDO)

40531-MK2-003   40531MK2003

40531MK2003
Not available
9
JOINT, DRIVE CHAIN (TAKASAGO)

40531-MK2-005   40531MK2005

40531MK2005
Not available
10
CLAMPER, CHAIN ADJUSTER

40546-KN5-000   40546KN5000

40546KN5000
Not available
11
WASHER, R. RR. FORK

42307-KN5-000   42307KN5000

42307KN5000
Not available
12
WASHER, L. RR. FORK

42308-KN5-000   42308KN5000

42308KN5000
Not available
13
STAY, TENSIONER

50143-MA0-770   50143MA0770

50143MA0770
Not available
14
FORK ASSY., RR. (WL)

52100-MK2-770   52100MK2770

52100MK2770
Not available
15
BUSH, PIVOT THRUST
BUSH, PIVOT THRUST

52109-430-300   52109430300

52109430300

Unit Price

16
HOOK, BRAKE SPRING

52115-KN5-000   52115KN5000

52115KN5000
Not available
17
COLLAR, RR. FORK CENTER

52141-KF0-000   52141KF0000

52141KF0000
Not available
18
CAP DUST SEAL
CAP DUST SEAL

52144-356-003  

52144-965-005
 52144356003

Unit Price

18
CAP, SWINGARM DUST SEAL (NOK)
CAP, SWINGARM DUST SEAL (NOK)

52144-356-005   52144356005

52144356005

Unit Price

19
GUIDE CHAIN

52146-MK2-000  

52146-KT1-770
 52146MK2000

Unit Price

20
SLIDER, CHAIN GUIDE
SLIDER, CHAIN GUIDE

52147-KN5-005   52147KN5005

52147KN5005

Unit Price

21
SLIPPER, CHAIN
SLIPPER, CHAIN

52155-KK0-771   52155KK0771

52155KK0771

Unit Price

22
PIN, CHAIN ADJUSTING

52156-KN5-000   52156KN5000

52156KN5000
Not available
23
COLLAR, CHAIN ROLLER

52159-169-000   52159169000

52159169000
Not available
24
SLIDER CHAIN

52170-KN5-000  

52170-KT1-770
 52170KN5000

Unit Price

25
WASHER, CHAIN SLIDER

52171-KR6-000   52171KR6000

52171KR6000

Unit Price

26
MARK, MUFFLER CAUTION

87504-028-670   87504028670

87504028670

Unit Price

26
MARK, MUFFLER CAUTION (FRENCH)

87504-428-720   87504428720

87504428720
Not available
28
SCREW, PAN, 5X12

90109-MK5-000   90109MK5000

90109MK5000
Not available
29
BOLT, RR. FORK PIVOT

90121-KN5-000   90121KN5000

90121KN5000
Not available
30
SCREW, FLAT, 5X4

90124-KA3-711   90124KA3711

90124KA3711

Unit Price

31
NUT, U, 6MM
NUT, U, 6MM

90301-473-003   90301473003

90301473003

Unit Price

32
NUT, U, 14MM

90305-GE8-003   90305GE8003

90305GE8003

Unit Price

33
NUT, FLANGE (SELF-LOCK) (M8X1.25)

90309-428-731   90309428731

90309428731

Unit Price

34
WASHER, 6X20

90512-300-000   90512300000

90512300000

Unit Price

35
BEARING, SWINGARM PIVOT (NTN)
BEARING, SWINGARM PIVOT (NTN)

91071-MA0-003   91071MA0003

91071MA0003

Unit Price

35
BEARING PIVOT

91071-MA0-004  

91071-MA0-003
 91071MA0004

Unit Price

37
SCREW, PAN, 5X12
SCREW, PAN, 5X12

93500-050120A   93500050120A

93500050120A

Unit Price

38
SCREW, FLAT, 6X45

93600-060450A   93600060450A

93600060450A

Unit Price

41
NIPPLE, GREASE (B.T6S)

96201-80000   9620180000

9620180000

Unit Price

42
BOLT, FLANGE, 6X12

96300-0601200   963000601200

963000601200

Unit Price

43
BOLT, FLANGE, 6X16

96300-0601600   963000601600

963000601600

Unit Price

44
BOLT, FLANGE, 6X45

96300-0604500   963000604500

963000604500

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the REAR ARM - CHAIN CASE of your Honda XR 600 R of XR. Let us know if you have any questions.

Genuine parts for Honda 1986 XR 600 R

Engine Frame

Honda 1986 XR 600 R

Please choose your model in the list above and click on its Genuine Spare Parts Catalogue

Color : R119
600 XR 1986 XR600RG
Color : R119

XR 600 R

Honda XR

Displacement: 600 cc
Year: 1986
Model code XR600RG
Color: R119
Drapeau CANADA
Canada
Single cylinder 4 stroke air cooled 591 cm3. Bore 97 x stroke 80 mm with 46hp at 6500rpm. 5 speed transmission. Single-shock rear suspensions and Pro Link linkage. Rear tire 110/100-17 and front 80/00-21. Front brake with a single 256 mm disc with 2 piston calipers.

Genuine maintenance parts

Spark Plug
17213-MN1-670
15410-KF0-315
Drain plug gasket

Technical specifications

Engine oil quantity:
1,95 Liters
