SWINGARM - CHAIN CASE FOR HONDA C 90 SELF STARTER 1995

REAR SHOCK ABSORBER

CASE, UPPER HALF DRIVE CHAIN *NH167MU* *PB121*

40510-GK4-600ZG 40510GK4600ZG

Not available

CASE, UPPER HALF DRIVE CHAIN *NH167MU* *R4*

40510-GK4-600ZG 40510GK4600ZG

Not available

CASE, UPPER HALF DRIVE CHAIN *NH167MU* *YR118*

40510-GK4-600ZG 40510GK4600ZG

Not available

CASE, UNDER HALF DRIVE CHAIN *NH167MU* *PB121*

40520-GK4-600ZG 40520GK4600ZG

Not available

CASE, UNDER HALF DRIVE CHAIN *NH167MU* *R4*

40520-GK4-600ZG 40520GK4600ZG

Not available

CASE, UNDER HALF DRIVE CHAIN *NH167MU* *YR118*

40520-GK4-600ZG 40520GK4600ZG

Not available

CHAIN, DRIVE (RK EXCEL) (RK420M-RJ)(98L)

40530-151-005 40530151005

Not available

CHAIN, DRIVE (DAIDO) (DID420M-RJ)(98L)

40530-179-701 40530179701

Not available

JOINT, DRIVE CHAIN (DAIDO)

40531-098-003 40531098003

6,25 $

Unit Price

JOINT, DRIVE CHAIN (DAIDO)

40531-098-003 40531098003

6,25 $

Unit Price

JOINT DRIVE CHAIN

40531-150-005

40531-045-671

6,25 $

Unit Price

JOINT DRIVE CHAIN

40531-153-003

40531-098-003

6,25 $

Unit Price

CAP, CHAIN CASE PEEP HOLE

40545-001-000 40545001000

6,53 $

Unit Price

PACKING, DRIVE CHAIN CASE

40591-041-000 40591041000

Not available

LINK, RR. BRAKE TORQUE

43431-086-720 43431086720

Not available

SPRING, STOPPER ARM

43434-250-000 43434250000

2,44 $

Unit Price

SWINGARM ASSY. *YR118MS* *YR118*

52000-GB6-761ZC 52000GB6761ZC

Not available

SWINGARM ASSY. *R4C* *R4*

52000-GB6-761ZD 52000GB6761ZD

Not available

SWINGARM ASSY. *PB121MS* *PB121*

52000-GB6-761ZE 52000GB6761ZE

Not available

CAP, CROSS MEMBER SIDE

52161-051-000 52161051000

3,79 $

Unit Price

BUSH, RR. FORK PIVOT RUBBER

52181-001-300 52181001300

15,13 $

Unit Price

BOLT-WASHER, 6X6

90118-383-000 90118383000

Not available

BOLT, RR. FORK PIVOT

90120-046-810 90120046810

Not available

COLLAR, MUFFLER SETTING

90122-141-650 90122141650

Not available

NUT, U, 10MM

90304-GE8-003 90304GE8003

5,43 $

Unit Price

BOLT WASHER 6X10

93411-0601000

Not available

NUT, HEX., 8MM

94001-080000S 94001080000S

1,53 $

Unit Price

WASHER, PLAIN, 8MM

94101-08000 9410108000

1,06 $

Unit Price

PIN, SPLIT, 2.0X15

94201-20150 9420120150

0,84 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SWINGARM - CHAIN CASE of your Honda C 90 self starter of CUB. Let us know if you have any questions.
